안테나시스템

Antenna System

50년 이상 축적된 CPI/General Dynamics/Andrew/Viasat의 안테나 설계와 공학기술을 바탕으로 HF 안테나로부터 위성 안테나까지 공급하고 있습니다.

Product Detail
  • Antenna Structures
    - 0.5m through 18m
  • RF Feed Systems
    - Dedicated & Multi-band
    - Low Passive Inter Modulation
    - Monopulse
  • Antenna Control Systems
    - GEO, MEO & LEO
  • Systems, Design/Engineering, Integration
Fixed Satellite Antenna
Antenna System

Satellite Antenna/Pedestals/Bands

Product Detail
  • Antennas & Pedestals 1m through 8m
  • Frequency Bands from L, S, & C for TT&C
    - Band/Aperture/Mount Specific
  • Frequency Bands through Ka for Satcom
    - Band/Aperture/Mount Specific
Satellite Antenna/Pedestals/Bands
Satellite Antenna/Pedestals/Bands

5.0m LEO Gateway

Product Detail
  • One or Two-Piece split, high gain, narrow-beam
    - directional antennas
  • X-Y pedestal with high precision (near-zero backlash) drives.
  • Conical Scanning feeds
  • 4-Port Circularly Polarized Combiner
  • RF Systems; LNAs, BDC’s, HPA’s, BUC’s
  • NGC Antenna Control Unit
  • Power and control interfaces.
  • Beacon Tracking Receiver
5.0m LEO Gateway

4.9m Earth Station Antennas

Product Detail
  • Aluminum Reflector, hub, backstructure
    - 12-Piece Stretch Formed
    - Dual Reflector Gregorian Optics
  • 2 Axis Subreflector Tracking
  • EL/AZ Positioner
    - Galvanized Steel, High Stiffness, High Strength
  • Direct to feed RF equipment mounting
  • Full Environmental Control System & Heater Systems
4.9m Earth Station Antennas

5.6m Earth Station Antennas

Product Detail
  • Aluminum Reflector, hub, backstructure
    - 16-Piece Stretch Formed
    - Dual Reflector Gregorian Optics
    - 3 Axis Subreflector Tracking
  • EL/AZ Positioner
    - High Stiffness, High Strength
  • Large Hub
    - 84” x 52”
  • Large Maintenance Platform & Ladder
  • Direct to feed RF equipment mounting
  • Full Environmental Control System & Heater Systems
5.6 m Earth Station Antennas

7.2m Antenna

C-Ku-band Model
C-Ku-band Model
Product Detail
  • No optical alignment required
    Gregorian Optics
  • C & Ku-band feed options
  • Optimized surface for Ku-band
    180o continuous azimuth travel
    mount option
Ku-Ka-band Model
Ku-Ka-band Model
Product Detail
  • High performance reflector for high frequency applications
    Ku-Ka band feed options
  • Cassegrain Optics
  • All aluminum trussed reflector
    180o continuous azimuth travel mount option
    Ka-band Large Hub option

8.1m Earth Station Antennas

Product Detail
  • Aluminum Reflector, hub, backstructure
    - 20-Piece Stretch Formed
    - 0.008” - 0.010” RMS
    - Dual Reflector Gregorian Optics
    - 3 Axis Subreflector Tracking
  • EL/AZ Positioner
    - Dual Motor Drive Azimuth
    - Dual Jackscrew Elevation
  • Large Hub
    - 84” x 52”
  • Large Maintenance Platform & Ladder
  • Direct to feed RF equipment mounting
  • Full Environmental Control System & Heater Systems
8.1m Earth Station Antennas

9.1m Antenna

Product Detail
  • Cassegrain Optics
  • C to DBS feed options
  • All aluminum trussed reflector Large platform option
  • 180o continuous azimuth travel mount option
  • Multi-band RO feed options
9.1m Antenna

9.4m Earth Station Antennas

Product Detail
  • Aluminum Reflector, hub, backstructure
    - 20-Piece Stretch Formed
    - 0.008” - 0.011” RMS
    - Dual Reflector Gregorian Optics
    - 3 Axis Subreflector Tracking
  • EL/AZ Positioner
    - Dual Motor Drive Azimuth
    - Dual Jackscrew Elevation
  • Large Hub
    - 84” x 52”
  • Direct to feed RF equipment mounting
  • Full Environmental Control System & Heater Systems
9.4m Earth Station Antennas

11.3m Antenna

11.3 m Antenna
Product Detail
  • Cassegrain Optics
  • C to DBS band feed options
  • All aluminum trussed reflector
  • Large platform option
  • 180o continuous azimuth travel mount option
  • Multi-band RO feed options
Turning-Head Model
Turning-Head Model
Product Detail
  • Turning Head mount provides
    - 360o azimuth travel in multiple 70o sectors
  • Higher wind performance than standard model

13.5m Antenna

13.5 m Antenna
Product Detail
  • Cassegrain optics
  • C & Ku, Ka-band feed options
  • All aluminum trussed reflector
  • Large platform option
  • Turning Head mount
  • provides 360o azimuth
  • travel in multiple 70o sectors

16/18m Antenna

16/18m Antenna
Product Detail
  • Cassegrain Optics
  • C-band feed options
  • Ku-band RO feed options
  • Galvanized mount & back-structure; optional paint
  • 360o azimuth travel in 6 overlapping 90o sectors
  • Turning Head mount provides
  • 360o azimuth travel in multiple 90o sectors
  • High wind options
